1.Fully automatic, microcomputer-controlled, set with 5 Pre-Programs and 25 Programmable settings for Washing , Time Period, Frequency as per requirement for different fabrics.
2.Different Washing setting programs for various types of fabrics.
3. Robust construction, Durable quality stainless steel panel & drum, acid and alkali resistance. corrosion free. 100% Free standing, foundation is not needed.
4. Whole Machine body structure is made of High Grade Stainless Steel Structure which ensures long life, durability of machine.
5. Equipped with Japanese NSK bearings ensures easy movement and self alignment of drum
6. Equipped with Frequency controlled motor for different washing speed which ensures delicate washing and extraction for delicate and soft fabrics.
7. Safety pneumatic lock system, ensures sealing prevents leakage, spillage of water from machine drum.
8. Each drum tested by dynamic balance machine and the gravity deviation no more than 20g.
9. Mechanical Full suspension shock structure, combination of shock absorbers and springs for maximum absorption and hydraulic damper for perfect running, Low Noise.
10. Built-out bearing lubrication, simple operation, and convenient maintenance.
11. Heating type: Both Electric Heating or Steam Heating or both together can be done in same machine asper customer’s requirement.
|
Model |
Unit |
ASWM-15F |
ASWM-30F |
ASWM-50F |
ASWM-100F |
|
Capacity |
kg |
15 |
30 |
50 |
100 |
|
Drum size |
mm |
700x440 |
880x560 |
990x670 |
1230x850 |
|
Drum volume |
L |
170 |
340 |
515 |
1009 |
|
Wash Speed |
r/min |
47 |
39 |
38 |
36 |
|
Voltage |
V |
380V 3P |
380V 3P |
380V 3P |
380V 3P |
|
Motor power |
kw |
1.5 |
4 |
5.5 |
7.5 |
|
Inverter power |
kw |
1.5 |
5.5 |
7.5 |
11 |
|
Washing Time |
mins |
35-55 |
35-55 |
35-55 |
35-55 |
|
Dimension |
mm |
1100x1100 x1580 |
1200x1200 x1730 |
1520x1630 x1990 |
1820x1960 x2250 |
|
Weight |
kg |
600 |
850 |
2000 |
3500 |
